10.4″ Panel Mount Titan & Poseidon Monitors

  • Shock and vibration isolation protection.
  • Water ingress protection from IP65 to full IP68.

Description

The Titan and Poseidon 10.4″ Panel Mount monitors are available in VGA SVGA and XGA resolution, and many different display options can be configured to suit a particular customers needs, including low power LED backlit sunlight readable high brightness displays, and all can be configured with touch screens.

Both RGB and composite video interfaces are possible with the ability to switch inputs as required. These monitors are small and compact and are ideally suited for a wide variety of extremely rugged vehicle, ship borne and marine applications where the monitor must be fitted into a control panel aperture and sealed to the panel.

They are highly suited to outdoor use for instance as external chart plotter repeater displays on boats and ships Examples of these extremely rugged and flexible monitors are widely used in marine chart plotting and other mission critical applications across a broad range of different platforms in both civilian and military areas, several variants have also been tested and qualified to Def Stan 59-41 and 08-123 for Naval below decks operation and are in service on the latest RN submarines. The design incorporates high degrees of protection to the display including shock and vibration isolation and these monitors have been though exhaustive testing programs for shock and vibration to military standards.

Different connector and cable configurations and specifications are available to suit all applications, and various degrees of ingress protection from IP65 to full IP68 can be offered.
